Case Study – Three Internal Retractable Spray Booths for Stainless Restoration

Factory & Warehouse PartitionIndustrial Bespoke

Aug 13 . 15 min read

Industrial Case Study

Stainless Restoration

Three bespoke internal retractable tunnels designed, manufactured and installed to create dedicated spray and work areas within an existing industrial facility.

Explore the project Discuss your requirements

Project overview

Creating three dedicated work areas within an existing facility

Stuart Canvas was approached by Stainless Restoration to provide a flexible solution for creating dedicated work areas within its existing industrial facility.

01 Client Stainless Restoration

02 Project Three Internal Retractable Spray Booths

03 Application Dedicated Spray & Work Areas

04 Service Design, Manufacture & Installation

Three individual retractable work areas — one flexible solution designed around the customer’s facility.

The customer required three separate internal spray booth areas that would provide controlled spaces for operational processes while maintaining the flexibility needed within a busy working environment.

Rather than introducing permanent internal structures, Stuart Canvas designed, manufactured and installed three bespoke retractable tunnels that can be deployed when required.

01 The challenge

Creating dedicated work zones without permanent partitioning

The requirement

Flexible separation within an active industrial facility

Stainless Restoration needed to improve the way different activities could be managed within its existing workspace.

The requirement was to create three dedicated areas suitable for spray and associated work while avoiding the restrictions that would come with permanently constructed rooms or partitions.

The objective

Dedicated areas without sacrificing valuable floor space

Each work area needed to operate independently while retaining the ability to retract the enclosure when the full space was not required.

The system also needed to provide clear separation between operational processes and withstand regular use in a demanding industrial environment.

Project requirements

Four priorities shaped the final solution

Three dedicated work areas

Create three individual spaces that could be used independently for spraying and other operational processes.

Flexible use of factory space

Ensure each work area could be retracted rather than permanently occupying valuable internal floor space.

Separation of processes

Provide clearly defined working environments to help separate individual activities from the wider facility.

Industrial durability

Develop a robust solution suitable for regular use within a demanding industrial environment.

02 Our solution

Three bespoke internal retractable spray booths

Bespoke manufacture

Designed around the customer’s existing facility

Following an assessment of the customer’s requirements, Stuart Canvas designed and manufactured three individual internal retractable tunnel systems.

Each tunnel creates a dedicated enclosed work area when extended, helping Stainless Restoration organise different processes within clearly defined working zones.

Retractable design

Space-saving flexibility built into every enclosure

Unlike permanent partitioning, each structure can be compacted when the full work area is not required, providing greater flexibility over how the available factory floor space is used.

Robust frameworks and heavy-duty PVC coverings create durable, practical enclosures suitable for regular operational use.

Complete solution

Designed, manufactured and installed by Stuart Canvas

The project was delivered as a complete solution from initial design and manufacture through to professional installation by the Stuart Canvas team.

01 3 bespoke internal retractable tunnels

02 Dedicated spray and work areas

03 Heavy-duty industrial construction

04 Retractable, space-saving design

05 Individual working zones

06 Designed around the existing facility

The installation

Three work areas. One integrated solution.

The finished installation creates a series of clearly defined industrial working areas while retaining the flexibility of the customer’s wider factory floor.

Flexible working areas

Creating space when and where it is needed

A major benefit of the installation is the flexibility it gives Stainless Restoration over its internal workspace.

When extended, each of the three tunnels provides a clearly defined work area suitable for spraying and associated operational activities.

When the full enclosure is not required, the retractable design allows the structure to occupy significantly less floor space.

The three-unit configuration provides further operational flexibility, allowing separate work zones to be utilised according to workload and production requirements.

Key benefits

A practical solution designed around the customer’s operation

The completed installation gives Stainless Restoration a flexible way to create and manage multiple work areas within its existing facility.

Three individual work areas

Independent retractable enclosures provide dedicated areas for different operational processes.

Flexible factory space

Each structure can be retracted when not required, helping maximise available internal floor space.

Process separation

Clearly defined work zones help separate individual activities from the wider working environment.

Industrial durability

Heavy-duty materials and robust construction provide a solution designed for regular industrial use.

Bespoke design

Every enclosure was developed around the dimensions and operational requirements of the existing facility.

Complete project delivery

Design, manufacture and professional installation were all delivered by the Stuart Canvas team.

Completed installation

Three purpose-built work areas successfully installed

The Stuart Canvas installation team successfully installed all three internal retractable tunnel systems within the Stainless Restoration facility.

The completed structures provide a practical combination of dedicated workspace and operational flexibility, allowing areas to be enclosed when required without introducing permanent internal rooms.

03 Systems installed

Customer satisfaction

A successful installation leading to further opportunities

The response from Stainless Restoration following completion of the project has been extremely positive.

The customer was very happy with both the completed retractable tunnel systems and the work carried out by the Stuart Canvas team.

Most importantly, the success of the initial installation has resulted in the customer requesting additional work to be quoted.

The result

Three flexible work areas — with further work already being discussed

The completed project has provided Stainless Restoration with three bespoke internal retractable spray booth areas, creating dedicated spaces for operational processes while maintaining flexibility across the wider facility.

The retractable configuration means the customer can create enclosed work areas when required without the restrictions associated with permanent internal partitioning.

With all three systems successfully installed and the customer now discussing additional requirements with Stuart Canvas, the project demonstrates how a bespoke retractable solution can develop alongside a customer’s future needs.

Project outcome

Three bespoke internal retractable spray booths successfully designed, manufactured and installed — creating flexible work areas and resulting in a highly satisfied customer who has already requested quotations for additional work.
